Saleae Logic Pro 8 – USB logic analyzer – Red

SaleaeSKU: EXP-R05-814

Price:
Sale price959,00 €

excl. VAT plus Versand

Stock:
Only 1 unit left

Manufacturer article number: SAL-00114
Customs tariff number: 90308400
Country of origin: US

✔ Fast dispatch within 24 hours
✔ Shipping from Germany
✔ Encrypted payment

Description

The Saleae Logic Pro 8 USB logic analyzer is a debugging tool for recording and displaying digital and analogue signals. The logic analyzer samples a digital input of the device under test (DUT) at a high sampling rate (500 MSa/s). These samples are recorded in a sample buffer and at the end of the capture, the buffer is displayed in the software for inspection. Since all digital channels are captured by an ADC, analogue displays are also possible with a sampling rate of 50 Msample/s. The Saleae logic analyzer supports various protocols, such as I2C, SPI, CAN, serial, etc.


Features:

  • Powerful and easy-to-use software
  • Deep sample buffer
  • Highly portable, USB attached
  • 24 protocol analysers
  • Automation API
  • Custom protocol decoder plugin API
  • Edge and pulse width triggering
  • Protocol result filtering and searching
  • Measurements, bookmarks and timing markers
  • Four data export formats: CSV, binary, VCD and MATLAB
  • Cross-platform Windows, Linux and OSX

Applications:

  • Firmware debugging
  • FPGA debugging
  • Function testing
  • Performance profiling
  • Reverse engineering
  • Protocol decoding
  • Data acquisition

Specifications:

  • Eight digital channels
  • 500 MSPS digital sampling (max)
  • 100 MHz max. digital bandwidth
  • Eight analogue channels
  • 50 MSPS analogue sampling (max)
  • 5 MHz analogue bandwidth
  • Recording length limited by available RAM and density of recorded data
  • RGB LED, 24-bit colour
  • USB 3.0 Super Speed

Dimensions:

  • 53 x 53 x 12 mm

Package contents:

  • 1x Saleae Logic Pro 8 USB logic analyzer
  • 2x 4-channel cable
  • 16x microgrip hooks
  • 1x Saleae carrying bag
  • 1x USB 3.0 cable
  • 1x manual
