Description
This module enables galvanically isolated, bidirectional I²C communication between two devices and simultaneously supplies the target device with regulated, isolated voltage (5V or 3.3V). The isolation prevents faulty connections or incorrect voltages from being transmitted from one side to the other and causing damage.
Technical data:
- Supply voltage:
- 4.5V - 5.5V → 5V (standard) or 3.3V (switchable) up to 200 mA
- 3.0V - 3.6V → 3.3V to 75 mA
- Bidirectional I²C communication: SDA & SCL with clock stretching
- Isolation: Signal & voltage isolation (prevents ground problems)
- Max. data rate: 1.7 MHz (TI ISO1640B)
- Protection functions: overtemperature & short-circuit protection
- Dimensions: 12.7 mm × 15.2 mm × 2.8 mm
- Weight: 0.5 g
- Connector: No
