Description
This module enables galvanically isolated, bidirectional I²C communication between two devices. SDA and SCL support clock stretching, so that the connection with different I²C devices works smoothly.
Technical data:
- Supply voltage:
- Side 1: 3.0V - 5.5V
- Page 2: 2.25V - 5.5V
- Galvanic isolation: Yes
- Bidirectional communication: Yes (SDA & SCL)
- Dimensions: 10.2 mm × 15.2 mm × 2.8 mm
- Weight: 0.4 g
- Connector: Yes, JST SH 4-pin
- Isolated power transmission: No
