VL53L5CX Time-of-Flight 8×8-Zone Distance Sensor Carrier with Voltage Regulator, 400cm Max

PololuSKU: EXP-R25-1567

Price:
Sale price15,96 €

excl. VAT plus Versand

Stock:
Only 5 units left

Manufacturer article number: 3417
Customs tariff number: 85423190
Country of origin: US

✔ Fast dispatch within 24 hours
✔ Shipping from Germany
✔ Encrypted payment

Description

This sensor is a carrier/breakout board for ST’s VL53L5CX laser-ranging sensor, which offers fast and accurate ranging up to 4 m through a digital I²C interface. It can measure absolute distances to multiple targets simultaneously across multiple zones, providing enough data for a depth map with up to 8×8 resolution. The board includes a 3.3 V linear regulator and level-shifters that allow it to work over an input voltage range of 2.8 V to 5.5 V, and the 0.1? pin spacing makes it easy to use with standard solderless breadboards and 0.1? perfboards.

Note: This is not recommended for use with 8-bit MCUs; for such applications, consider the VL53L1X or VL53L0X carrier.

Specifications:
  • Size: 13 mm × 18 mm × 2 mm
  • Weight: 0.5 g
  • Operating voltage: 2.8 V to 5.5 V
  • Supply current: ~100 mA (typical average during active ranging with default settings)
  • Peak current can reach 150 mA
  • Maximum range: 4 m
  • Resolution: 1 mm depth, 4×4 or 8×8 sensor zones
  • Minimum range: 20 mm
  • Emitter: 940 nm invisible Class 1 VCSEL (vertical cavity surface-emitting laser) – eye-safe
  • Detector: SPAD (single photon avalanche diode) receiving array
  • Typical full field of view (FoV): 63° diagonal (45° horizontal/vertical)
  • Output format (I²C): histogram
